CLUTCH PEDAL, CLUTCH MASTER CYLINDER
H7
H
Clutch Pedal Installation Note
1. After installation, adjust the pedal height and free play. (See H5 CLUTCH PEDAL ADJUSTMENT.)
End Of Sie
CLUTCH MASTER CYLINDER REMOVAL/INSTALLATION
A6E491641990W01
1. Remove the battery and battry tray. (European (L.H.D.), GCC. specs.)
2. Remove in the order indicated in the table.
3. Plug the clutch pipe after removing it to avoid leakage.
4. Install in the reverse order of removal.
.
End Of Sie
11 Pedal pad
12 Clutch pedal
(See H7 Clutch Pedal Installation Note)
CLUTCH MASTER CYLINDER
A6E4916W001
1Clip
2 Clutch pipe
3Nut
4 Clutch master cylinder
5Gasket
