Mazda 6 2002 - Liftgate Adjustment

LIFTGATE
S45
S
LIFTGATE ADJUSTMENT
A6E772262010W03
1. Measure the gap and height between the liftgate and the body.
2. If not as specified, loosen the liftgate hinge
installation bolts or the liftgate striker installation
screws, and reposition the liftgate.
Clearance
a: 3.07.0 mm {0.120.28 in}
b: -1.03.4 mm {-0.04013 in}
c: 2.85.2 mm {0.110.24 in}
d: -1.21.2 mm {0.050.05 in}
e: 2.85.8 mm {0.110.22 in}
f:4.08.0 mm {0.160.31 in}
3. Tighten the bolts or screws.
End Of Sie
A6E7722W004
