Mazda 6 2002 - Instrument Cluster Input;Output Check Mode

WARNING AND INDICATOR SYSTEM
T75
T
INSTRUMENT CLUSTER INPUT/OUTPUT CHECK MODE
A6E811855430W06
Note
• In this mode, it is possible to check the items in the following chart.
Diagnostic Trouble Code Chart
Note
• Diagnostic trouble codes which are not listed may be indicated, but they cannot be inspected.
• The diagnostic trouble codes are displayed in numerical order. (While performing the inspection, if you
want to inspect a diagnostic trouble code of which the number is smaller than the code number you are
currently inspecting, terminate the check mode then repeat the inspection from the beginning.)
• If the speed signal is put into the instrument cluster (the front wheels are rotated) while a code other than
DTC 00 is display, the input/output check mode will be cancelled.
• The diagnostic trouble codes can be fast-forwarded by pushing and holding the odometer/tripmeter switch
for 1 second or more.
DTC Checked item Related item
01 Buckle switch Buckle switch
04 Door switch
• Ignition key illumination
• Key reminder warning buzzer
• Interior light control
• Power door lock system
• Lights-on reminder warning buzzer
08 TNS relay
• Lights-on reminder warning buzzer
• Each illumination
12 Speedometer Speedometer
13 Tachometer Tachometer
14 Buzzer Buzzer
16 Fuel-level warning light Fuel-level warning light
18 Ignition key cylinder illumination Ignition key cylinder illumination
22 Fuel gauge sender unit Fuel gauge
23 Fuel gauge Fuel gauge
25 Water temperature gauge Water temperature gauge
26 LCD LCD
31 Key reminder switch Key reminder warning buzzer
