Mazda 6 2002 - Outside Mirror; Power Outside Mirror Removal;Installation; Power Outside Mirror Disassembly;Assembly

S58
OUTSIDE MIRROR
POWER OUTSIDE MIRROR REMOVAL/INSTALLATION
A6E773269110W01
1. Disconnect the negative battery cable.
2. Remove the inner garnish.
3. Remove the front door trim.
4. Disconnect the power outside mirror connector.
5. Remove the screws and the mirror retention clips.
6. Remove the power outside mirror.
7. Install in the reverse order of removal.
End Of Sie
POWER OUTSIDE MIRROR DISASSEMBLY/ASSEMBLY
A6E773269110W02
1. Disassemble in the order indicated in the table.
2. Assemble in the reverse order of disassembly.
Outside Mirror Glass Disassembly Note
1. Press area A of the glass so that area B moves
toward you.
2. Insert a screwdriver into the notch and remove
the glass from the mirror base.
OUTSIDE MIRROR
A6E7732W006
1 Outside mirror glass
(See S58 Outside Mirror Glass Disassembly Note)
(See S59 Outside Mirror Glass Assembly Note)
2 Connector (with heated outside mirror)
3Cover
(See S59 Cover Disassembly Note)
4 Outside mirror holder
A6E7732W002
A6E7732W003
