Mazda 6 2002 - Audio Amplifier Removal;Installation; Audio Control Switch Inspection

T100
AUDIO AND NAVIGATION SYSTEM
AUDIO CONTROL SWITCH INSPECTION
A6E812400148W02
1. Disconnect the negative battery cable.
2. Remove the driver-side air bag module. (See T120 DRIVER-SIDE AIR BAG MODULE REMOVAL/
INSTALLATION.)
3. Disconnect the audio control switch connector.
4. Measure the resistance and inspect for continuity
between the cruise control switch terminals using
an ohmmeter.
• If not as specified, replace the cruise control
switch.
End Of Sie
AUDIO AMPLIFIER REMOVAL/INSTALLATION
A6E812466910W01
1. Disconnect the negative battery cable.
2. Remove in the order indicated in the table.
3. Install in the reverse order of removal.
End Of Sie
A6E8124W043
A6E8124W028
1Bolt
2 Connector
3 Audio amplifier
A6E8124W010
