Mazda 6 2002 - Front Lower Arm (Rear) Removal;Installation

FRONT SUSPENSION
R19
R
FRONT LOWER ARM (REAR) REMOVAL/INSTALLATION
A6E741434300W02
1. Remove the front crossmember component.
(See R23 FRONT CROSSMEMBER REMOVAL/INSTALLATION.)
2. Remove in the order indicated in the table.
3. Install in the reverse order of removal.
4. Inspect the front wheel alignment.
(See R5 FRONT WHEEL ALIGNMENT.)
.
Front Lower Arm (Rear) Ball Joint Removal Note
1. Separate the ball joint from the knuckle using the
SSTs.
A6E7414W019
1 Front lower arm (rear) ball joint
(See R19 Front Lower Arm (Rear) Ball Joint
Removal Note)
2 Front lower arm (rear)
(See R21 Front Lower Arm (Rear) Installation
Note)
3Clip
R21 Clip Installation Note
4 Dust boot
5 Front lower arm (rear) bushing
(See R20 Front Lower Arm (Rear) Bushing
Removal Note)
(See R20 Front Lower Arm (Rear) Bushing
Installation Note)
A6E7414W031
