Mazda 6 2002 - Rear Map Light Removal;Installation; Rear Map Light Inspection

INTERIOR LIGHTING SYSTEM
T49
T
REAR MAP LIGHT REMOVAL/INSTALLATION
A6E811451311W01
1. Disconnect the negative battery cable.
2. Remove in the order indicated in the table.
3. Install in the reverse order of removal.
Rear Map Light Removal Note
1. Insert a tape-wrapped flathead screwdriver into the gap between the headliner and the rear map light.
2. Push the hooks to remove the rear map light.
End Of Sie
REAR MAP LIGHT INSPECTION
A6E811451311W02
1. Remove the rear map light. (See T49 REAR MAP LIGHT REMOVAL/INSTALLATION.)
2. Inspect for continuity between the rear map light
terminals using an ohmmeter.
• If not as specified, replace the rear map light.
End Of Sie
1 Rear map light (See T49 Rear Map Light Removal
Note)
2 Connector
3Socket
4 Rear map light bulb
A6E8114W104
A6E8114W105
A6E8114W128
A6E8114W127
