Mazda 6 2002 - Liftgate Lower Trim Removal;Installation

TRIM
S95
S
3. Pull the liftgate side trim toward you, then
disengage clips A, pin B and the strap hanger
from the body and pin B, hook C, D from the
liftgate lower trim.
4. Remove the liftgate side trim.
5. Remove the hanger strap from the liftgate side
trim.
6. Install in the reverse order of removal.
End Of Sie
LIFTGATE LOWER TRIM REMOVAL/INSTALLATION
A6E774468960W01
1. Remove the liftgate upper trim.
2. Remove the liftgate side trim.
3. Pull the handle toward you, then remove the
handle.
4. Pull the liftgate lower trim toward you, then
disengage clips A, B and pins C, D from the body.
5. Remove the liftgate lower trim.
6. Install in the reverse order of removal.
End Of Sie
A6E7744W004
A6E7744W001
