Mazda 6 2002 - Headlight Cleaner Nozzle; Headlight Cleaner Nozzle Cleaning

T70
WIPER AND WASHER
HEADLIGHT CLEANER MOTOR INSPECTION
A6E811651030W02
1. Disconnect the negative battery cable.
2. Remove the washer tank. (See T58 WASHER TANK REMOVAL/INSTALLATION)
3. Connect battery positive voltage to terminal D and ground to terminal C of the motor.
4. Verify that the headlight cleaner motor operates.
• If the motor does not operate, replace the
headlight cleaner motor.
End Of Sie
HEADLIGHT CLEANER NOZZLE REMOVAL/INSTALLATION
A6E811651030W03
1. Remove the front bumper. (See S47 FRONT BUMPER REMOVAL/INSTALLATION)
2. Disconnect the headlight cleaner hose. (See T71 HEADLIGHT CLEANER HOSE REMOVAL/
INSTALLATION)
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.
5. Adjust the headlight cleaner nozzle. (See T70
HEADLIGHT CLEANER NOZZLE
ADJUSTMENT.)
End Of Sie
HEADLIGHT CLEANER NOZZLE ADJUSTMENT
A6E811651030W04
1. Use a needle or equivalent to adjust the headlight
cleaner nozzle so that the center of fluid properly
sprays on the headlight as shown in the figure.
End Of Sie
HEADLIGHT CLEANER NOZZLE CLEANING
A6E811651030W05
1. Clean the rear washer nozzle. (See T60 WINDSHIELD WASHER NOZZLE CLEANING.)
End Of Sie
A6E8116W137
1Screw
2 Spacer
3 Headlight cleaner nozzle
A6E8116W142
A6E8116W115
