Mazda 6 2002 - Washer Tank

T58
WIPER AND WASHER
WINDSHIELD WIPER ARM AND BLADE ADJUSTMENT
A6E811667320W02
1. Operate the windshield wiper motor to set the wipers in the park position.
2. Set the windshield wiper arms height as shown.
End Of Sie
WASHER TANK REMOVAL/INSTALLATION
A6E811667481W01
1. Disconnect the negative battery cable.
2. Remove in the order indicated in the table.
3. Install in the reverse order of removal.
End Of Sie
A6E8116W107
1Bolt
2 Connector
3 Washer hose
4 Clip
5 Headlight cleaner hose
6 Washer tank
A6E8116W117
