WIPER AND WASHER
T59
T
WINDSHIELD WASHER MOTOR REMOVAL/INSTALLATION
A6E811676670W01
1. Disconnect the negative battery cable.
2. Remove the washer tank. (See T58 WASHER TANK REMOVAL/INSTALLATION)
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.
End Of Sie
WINDSHIELD WASHER MOTOR INSPECTION
A6E811676670W02
1. Disconnect the negative battery cable.
2. Remove the washer tank. (See T58 WASHER TANK REMOVAL/INSTALLATION)
3. Connect battery positive voltage to the motor
terminal B and ground to the motor terminal A.
4. Verify that the windshield washer motor operates.
• If the motor does not operate, replace the
windshield washer motor.
End Of Sie
WASHER FLUID-LEVEL SENSOR REMOVAL/INSTALLATION
A6E811676670W03
1. Disconnect the negative battery cable.
2. Remove the washer tank. (See T58 WASHER TANK REMOVAL/INSTALLATION)
3. Remove the headlight cleaner motor. (See T69 HEADLIGHT CLEANER MOTOR REMOVAL/
INSTALLATION)
4. Remove in the order indicated in the table.
5. Install in the reverse order of removal.
End Of Sie
1 Windshield washer motor
2Grommet
A6E8116W123
A6E8116W129
1 Connector
2 Washer fluid-level sensor
3Grommet
A6E8116W114
