Mazda 6 2002 - Transverse Member

FRONT SUSPENSION
R27
R
TRANSVERSE MEMBER REMOVAL/INSTALLATION
A6E741434890W01
1. Remove in the order indicated in the table.
2. Install in the reverse order of removal.
Transverse Cover Installation Note
1. Install the transverse cover.
2. Stake area A as shown in the figure.
End Of Sie
1 Transverse member and transverse cover
2 Transverse cover (European (L.H.D. U.K.) specs.)
(See R27 Transverse Cover Installation Note)
3 Transverse member
A6E7414W037
A6E7414W038
