TRUNK LID
S41
S
TRUNK LID ADJUSTMENT
A6E772052610W03
1. Measure the gap and height between the front door and the body.
2. If not as specified, loosen the door hinge
installation bolts or the door lock striker
installation screws, and reposition the door.
Clearance
a: 2.54.5 mm {0.100.18 in}
b: -1.01.0 mm {-0.040.04 in}
c: 4.08.0 mm {0.160.31 in}
3. Tighten the bolts or screws.
End Of Sie
STAY DAMPER DISPOSAL
A6E772052610W04
Note
• The gas in the stay damper is colorless, odorless, and non-toxic.
1. Wear protective eye wear.
2. Lay the stay damper flat.
3. Saw through the stay damper body using a
hacksaw.
4. Allow the gas to escape from the stay damper.
5. Discard the stay damper.
End Of Sie
A6E7720W005
A6E7722W006
