Mazda 6 2002 - Intruder Sensor Removal;Installation; Theft-Deterrent Siren Removal;Installation

THEFT-DETERRENT SYSTEM
T89
T
INTRUDER SENSOR REMOVAL/INSTALLATION
A6E812000172W01
1. Disconnect the negative battery cable.
2. Remove the headliner.
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.
.
End Of Sie
THEFT-DETERRENT SIREN REMOVAL/INSTALLATION
A6E812000173W01
1. Disconnect the negative battery cable.
2. Remove the left side trunk side trim.
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.
End Of Sie
A6E8120W005
1 Connector
2Screw
3 Intruder sensor
1Nut
2 Connector
3 theft-deterrent siren
A6E8120W006
