B10
COMPRESSION PRESSURE, TIMING CHAIN
kPa {kgf/cm
2
, psi} [rpm]
11. Disconnect the compression gauge.
12. Install the spark plugs. (See G10 SPARK PLUG REMOVAL/INSTALLATION.)
13. Connect the ignition coil connector.
14. Install the fuel pump relay. (See F17 BEFORE REPAIR PROCEDURE.)
End Of Sie
TIMING CHAIN REMOVAL/INSTALLATION
A6E221512201W01
Warning
•
••
• Fuel vapor is hazardous. It can very easily ignite, causing serious injury and damage. Always keep
sparks and flames away from fuel.
•
••
• Fuel line spills and leakage are dangerous. Fuel can ignite and cause serious injures or death and
damage. Fuel can also irritate skin and eyes. To prevent this, always complete the Fuel Line
Safety Procedure. (See F17 Fuel Line Safety Procedure.)
1. Disconnect the negative battery cable.
2. Remove the spark plugs. (See G10 SPARK PLUG REMOVAL/INSTALLATION.)
3. Remove the tire (RH).
4. Remove the under cover.
5. Loosen the water pump pulley bolt and removal the drive belt. (See B3 DRIVE BELT REPLACEMENT.)
6. Remove the CKP sensor. (See F54 CRANKSHAFT POSITION (CKP) SENSOR REMOVAL/INSTALLATION.)
7. Drain the engine oil. (See D4 ENGINE OIL REPLACEMENT.)
8. Remove the P/S oil pump with the oil hose still connected and position the P/S oil pump so that it is out of the
way. (See N22 POWER STEERING OIL PUMP REMOVAL/INSTALLATION.)
9. Remove the front drive shaft (RH) from the joint shaft. (See M12 JOINT SHAFT REMOVAL/INSTALLATION.)
10. Remove in the order indicated in the table.
11. Install in the reverse order of removal.
12. Start the engine and:
• Inspect for the engine oil, engine coolant, transaxle oil and fuel leakage.
• Verify the ignition timing, idle speed and idle mixture. (See F8 IGNITION TIMING INSPECTION.) (SeeF
9 IDLE MIXTURE INSPECTION.)
13. Perform a road test.
Item
Engine type
L3
Standard 1,430 {14.5819, 207.404} [290]
Minimum 1,000 {10.197, 145.00} [290]
Maximum difference
between cylinders
196.1 {1.999, 28.44}
TIMING CHAIN
