Mazda 6 2002 - Oil Pan; Oil Pan Removal;Installation

D8
OIL PAN
OIL PAN REMOVAL/INSTALLATION
A6E332010040W01
Warning
•
••
• Hot engine and engine oil can cause severe burns. Turn off the engine and wait until it and the
engine oil have cooled.
1. Disconnect the negative battery cable.
2. Remove the under cover.
3. Drain the engine oil. (See D4 ENGINE OIL REPLACEMENT.)
4. Remove the engine front cover. (See B10 TIMING CHAIN REMOVAL/INSTALLATION.)
5. Remove in the order indicated in the table.
6. Install in the reverse order of removal.
7. Inspect the oil level. (See D4 ENGINE OIL INSPECTION.)
8. Start the engine and inspect for oil leakage.
• If the oil leaks, specify the faulty part and repair or replace it.
.
OIL PAN
AME3320W001
1 Oil level gauge pipe 2 Oil pan (See D9 Oil Pan Installation Note)
