H10
CLUTCH RELEASE CYLINDER
CLUTCH RELEASE CYLINDER DISASSEMBLY/ASSEMBLY
A6E491841920W02
1. Disassemble in the order indicated in the table.
2. Assemble in the reverse order of disassembly.
.
End Of Sie
A6E4918W002
1 Boot
2 Push rod
3 Piston and cap
4 Return spring
5 Bleeder cap
6 Bleeder screw
7 Release cylinder body
