Mazda 6 2002 - Transaxle Range (Tr) Switch Removal;Installation

AUTOMATIC TRANSAXLE
K15
K
3. Disconnect the TR switch connector.
4. Inspect for continuity at the TR switch.
• If not as specified, adjust the TR switch and
go to Step 4.
5. Reinspect for continuity at TR switch.
• If not as specified, replace the TR switch.
(See K15 TRANSAXLE RANGE (TR)
SWITCH REMOVAL/INSTALLATION.)
6. Connect the TR switch connector.
7. Install the air cleaner component. (See F10
INTAKE-AIR SYSTEM REMOVAL/
INSTALLATION.)
8. Connect the negative battery cable.
End Of Sie
TRANSAXLE RANGE (TR) SWITCH REMOVAL/INSTALLATION
A6E561419440W02
1. Disconnect the negative battery cable.
2. Remove the air cleaner component. (See F10 INTAKE-AIR SYSTEM REMOVAL/INSTALLATION.)
Caution
•
••
• Water or foreign objects entering the connector can cause a poor connection or corrosion. Be
sure not to drop water or foreign objects on the connector when disconnecting it.
3. Disconnect the TR switch connector.
4. Remove the clip and disconnect the selector
cable.
Caution
•
••
• Do not use an impact wrench. Hold the
manual shaft lever when removing the
manual shaft nut, or the transaxle may be
damaged.
5. Set the adjustable wrench as shown to hold the
manual shaft lever.
6. Remove the manual shaft nut and washer.
A6E5614W008
A6E5614W010
A6E5614W011
A6E5614W100
