Mazda 6 2002 - Dtc P0602; Dtc P0610

F152
ON-BOARD DIAGNOSTIC
DTC P0602
A6E397001088W01
Diagnostic procedure
End Of Sie
DTC P0610
A6E397001088W02
Diagnostic procedure
DTC P0602 PCM programming error
DETECTION
CONDITION
• No configuration data in PCM
Note
• If PCM CONFIGURATION is successful, the PCM stored DTC P0602 and illuminates the MIL
(System i s normal) Clear the DTC P0602 using WDS or equivalent after PCM CONFIGURATION.
• MIL goes off after three drive cycles with no failure (DTCs remain in PCM).
POSSIBLE
CAUSE
• Complete configuration has not been completed.
• PCM malfunction
STEP INSPECTION ACTION
1 PERFORM DTC CONFIRMATION PROCEDURE
• Perform DTC CONFIRMATION PROCEDURE.
(See F66 DTC CONFIRMATION
PROCEDURE.)
• Is same DTC present?
Yes Perform PCM configuration procedure, then go to next
step.
(See F50 PCM CONFIGURATION.)
No Intermittent concern exists. Go to INTERMITTENT
CONCERN TROUBLESHOOTING procedure.
(See F227 INTERMITTENT CONCERN
TROUBLESHOOTING.)
2 VERIFY TROUBLESHOOTING OF DTC P0602
COMPLETED
• Make sure to reconnect all disconnected
connectors.
• Turn ignition key to ON (Engine OFF).
• Clear DTC from PCM memory using WDS or
equivalent.
• Perform KOEO/KOER self-test.
(See F66 KOEO/KOER SELF-TEST.)
• Is same DTC present?
Yes Replace PCM, then go to next step.
(See F43 PCM REMOVAL/INSTALLATION.)
No Go to next step.
3 VERIFY AFTER REPAIR PROCEDURE
• Perform After Repair Procedure.
(See F66 AFTER REPAIR PROCEDURE.)
• Is there any DTC present?
Yes Go to applicable DTC troubleshooting.
(See F67 DTC TABLE.)
No Troubleshooting completed.
DTC P0610 Control module vehicle options error
DETECTION
CONDITION
• PCM data configuration error
POSSIBLE
CAUSE
• Configuration procedure has not been completed
• PCM malfunction
STEP INSPECTION ACTION
1 PERFORM DTC CONFIRMATION PROCEDURE
• Perform DTC CONFIRMATION PROCEDURE.
(See F66 DTC CONFIRMATION
PROCEDURE.)
• Is same DTC present?
Yes Perform PCM configuration procedure, then go to next
step.
(See F50 PCM CONFIGURATION.)
No Intermittent concern exists. Go to INTERMITTENT
CONCERN TROUBLESHOOTING procedure.
(See F227 INTERMITTENT CONCERN
TROUBLESHOOTING.)
2 VERIFY TROUBLESHOOTING OF DTC P0610
COMPLETED
• Make sure to reconnect all disconnected
connectors.
• Turn ignition key to ON (Engine OFF).
• Clear DTC from PCM memory using WDS or
equivalent.
• Perform KOEO/KOER self-test.
(See F66 KOEO/KOER SELF-TEST.)
• Is same DTC present?
Yes Replace PCM, then go to next step.
(See F43 PCM REMOVAL/INSTALLATION.)
No Go to next step.
3 VERIFY AFTER REPAIR PROCEDURE
• Perform After Repair Procedure.
(See F66 AFTER REPAIR PROCEDURE.)
• Is there any DTC present?
Yes Go to applicable DTC troubleshooting.
(See F67 DTC TABLE.)
No Troubleshooting completed.
