OIL COOLER
D7
D
OIL COOLER REMOVAL/INSTALLATION
A6E331819900W01
LF, L3
1. Remove the under cover.
2. Drain the engine coolant. (See E3 ENGINE COOLANT REPLACEMENT.)
3. Remove the oil filter cover, and drain the engine oil into a container. (See D6 OIL FILTER REPLACEMENT.)
4. Remove in the order indicated in the table.
5. Use a clean rag to wipe off the mounting surface
on the oil cooler.
6. Install in the reverse order of removal.
7. Inspect the oil level.
• If necessary, add oil. (See D4 ENGINE OIL
INSPECTION.)
8. Start the engine and inspect for oil leakage.
• If the oil leaks, specify the faulty part and
repair or replace it.
End Of Sie
OIL COOLER
1 Water hose
2 Oil cooler
AME3318W002
