Mazda 6 2002 - Seat Warmer Switch Removal;Installation; Seat Warmer Switch Inspection

SEAT
S117
S
SEAT WARMER SWITCH REMOVAL/INSTALLATION
A6E775259000W01
1. Disconnect the negative battery cable.
2. Remove the brake boots panel. (See S86 CONSOLE REMOVAL/INSTALLATION.)
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.
Seat Warmer Switch Removal Note
1. Squeeze the tabs of seat warmer switch and pull it forward to remove it.
End Of Sie
SEAT WARMER SWITCH INSPECTION
A6E775259000W02
1. Remove the seat warmer switch.
2. Inspect for continuity between the seat warmer switch terminals using an ohmmeter.
• If not as specified, replace the seat warmer switch.
Drivers side
Passengers side
End Of Sie
1 Seat warmer switch
(See S117 Seat Warmer Switch Removal Note.)
2 Connector
A6E7752W001
A6E7752W024
A6E7752W025
A6E7752W024
A6E7752W026
