Mazda 6 2002 - Rear Washer Motor; Windshield Washer Hose

WIPER AND WASHER
T61
T
WINDSHIELD WASHER HOSE REMOVAL/INSTALLATION
A6E811650601W01
1. Remove the bonnet insulator.
2. Partially peel off the right side mud guard.
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.
End Of Sie
REAR WASHER MOTOR REMOVAL/INSTALLATION
A6E811676672W01
1. Disconnect the negative battery cable.
2. Remove the washer tank. (See T58 WASHER TANK REMOVAL/INSTALLATION)
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.
End Of Sie
REAR WASHER MOTOR INSPECTION
A6E811676672W02
1. Disconnect the negative battery cable.
2. Remove the washer tank. (See T58 WASHER TANK REMOVAL/INSTALLATION)
3. Connect battery positive voltage to the terminal B and ground to the terminal A of the motor.
4. Verify that the rear washer motor operates.
• If the motor does not operate, replace the rear
washer motor.
End Of Sie
1Clip
2 Joint pipe
3 Windshield washer hose
A6E8116W126
1 Rear washer motor
2Grommet
A6E8116W104
A6E8116W131
