Mazda 6 2002 - Rear Side Seat Belt Removal;Installation; Rear Center Seat Belt Removal;Installation

SEAT BELT
S101
S
REAR SIDE SEAT BELT REMOVAL/INSTALLATION
A6E775057730W01
Caution
•
••
• The ELR has a spring that will unwind if the retractor's cover is removed. The spring cannot be
rewound by hand. If this occurs, the ELR will not work properly. Therefore, do not disassemble the
retractor.
4SD
1. Fold the rear seat back.
2. Remove the rear side seats.
3. Remove the rear package trim.
4. Remove the bolts.
5. Remove the rear seat belt.
6. Install in the reverse order of removal.
5HB
Note
• Rear side seat belts are embedded in the rear seat back. See rear seat disassembly/assembly, remove/
install the rear center seat belt.
End Of Sie
REAR CENTER SEAT BELT REMOVAL/INSTALLATION
A6E775057730W02
Caution
•
••
• The ELR has a spring that will unwind if the retractor's cover is removed. The spring cannot be
rewound by hand. If this occurs, the ELR will not work properly. Therefore, do not disassemble the
retractor.
4SD
1. Fold the rear seat back.
2. Remove the rear package trim.
3. Remove the bolt.
4. Remove the rear center seat belt.
5. Install in the reverse order of removal.
A6E7750W005
A6E7750W003
