ON-BOARD DIAGNOSTIC
K85
K
DTC P0753
A6E567001030W22
DTC P0753 Shift solenoid A malfunction (electrical)
DETECTION
CONDITION
• If PCM detects either of following conditions, PCM determines that shift solenoid A circuit has a
malfunction:
Shift solenoid A voltage is stuck at B+ after engine start.
Shift solenoid A voltage is stuck at 0 V after engine start.
Diagnostic support note:
• This is a continuous monitor (CCM).
• MIL illuminates if PCM detects the above malfunction conditions during first drive cycle.
• PENDING CODE is not available.
• FREEZE FRAME DATA is available.
• HOLD indicator light flashes.
• DTC is stored in the PCM memory.
POSSIBLE
CAUSE
• Shift solenoid A malfunction
• Short to ground between ATX connector terminal A and PCM terminal 4AB
• Short to power between ATX connector terminal A and PCM terminal 4AB
• Open circuit between shift solenoid A terminal B and ATX connector terminal A
• Open circuit between ATX connector terminal A and PCM terminal 4AB
• Open circuit between shift solenoid A terminal A and body ground point
• Damaged connector between shift solenoid A and PCM
• PCM malfunction
To Next Page
