S44
LIFTGATE
LIFTGATE DISASSEMBLY/ASSEMBLY
A6E772262010W02
1. Disconnect the negative battery cable.
2. Remove the liftgate lower trim.
3. To remove the liftgate outer handle and liftgate key cylinder, remove the rear finisher.
4. To remove the stud ball, separate the stud ball and the stay damper.
5. Disassemble in the order indicated in the table.
6. Assemble in the reverse order of disassembly.
.
End Of Sie
STAY DAMPER DISPOSAL
A6E772262620W01
1. Referring to procedures for trunk lid stay damper disposal, dispose of the liftgate stay damper.
End Of Sie
A6E7722W007
1 Liftgate latch and lock actuator
2 Liftgate outer handle
3 Liftgate key cylinder
4 Clip
5 Stud ball
6 Liftgate wedge
7 Liftgate dovetail
8 Liftgate
9Stpper
