Mazda 6 2002 - Page 516

REAR AXLE
M11
M
ABS Sensor Rotor Removal Note
Note
• The sensor rotor does not need to be removed unless it is being replaced.
1. Remove the sensor rotor using a chisel.
ABS Sensor Rotor Installation Note
Caution
•
••
• Position the SST so that marking B faces the bottom.
1. Set the SST as shown in the figure.
2. Press on the new sensor rotor using the SST and
a press.
Locknut Installation Note
1. Install a new locknut and stake it as shown.
A6E6314W001
A6E0313W011
A6E0313W012
A6E0313W013
