TIMING CHAIN
B13
B
Oil Pump Sprocket Removal Note
1. Hold the oil pump sprocket by using the SST.
Engine Front Cover Removal Note
1. Remove the oil seal using a screwdriver as
shown.
Oil Pump Sprocket Installation Note
1. Hold the oil pump sprocket by using the SST.
AME2215W005
AME2215W006
AME2215W005
