ENGINE SPEED SENSING POWER STEERING
N11
N
Bolt (Intermediate Shaft) Removal Note
1. Mark the pinion shaft and gear housing for proper
installation.
Tie-rod End Ball Joint Removal Note
1. Remove the tie rod-nut.
2. Separate the tie-rod end from the steering
knuckle using the SSTs.
Steering Gear and Linkage Removal Note
L.H.D.
Caution
•
••
• Excessively loosening the crossmember nuts may possibly cause the crossmember to fall off.
The crossmember nuts must remain threaded on the studs when loosening.
1. Support the crossmember using jack before
removing the crossmember bracket.
2. Loosen the jack and lower the crossmember.
3. Remove the steering gear and linkage by pulling
it from the left side.
R.H.D.
1. Remove the steering gear and linkage by pulling it from the right side.
A6E0612W084
A6E0612W085
A6E0612W107
