DYNAMIC STABILITY CONTROL
P43
P
COMBINE SENSOR INSPECTION
A6E692067650W06
Caution
•
••
• Be careful and do not allow the lateral-G sensor to fall. If by chance it is subjected to strong
impact, replace it.
1. Connect the connector.
2. Turn ignition switch on, verify the voltage between
terminals B and E under the following conditions.
• If not within the specification, replace the
lateral-G sensor.
(1) Lateral-G
1) Horizontal
Voltage
2.42.6 V
2) Facing up (inclined 90° from horizontal)
Voltage
3.33.7 V
3) Facing down (declined 90° from
horizontal)
Voltage
1.31.7 V
(2) Yaw rate
1) Measure yaw rate sensor voltage under
static condition.
A6E6920W008
A6E6920W002
A6E6920W003
A6E6920W008
