B24
FRONT OIL SEAL
2. Install the M6 x 1.0 bolt in by hand.
3. Turn the crankshaft clockwise the crankshaft is in
the No.1 cylinder TDC position.
4. Hold the crankshaft pulley by using the SSTs.
5. Tighten the crankshaft pulley lock bolt in the order
shown using the following two steps.
(1) Tighten to 96104 N·m {9.810.6 kgf·m,
70.976.7 ft·lbf}
(2) Tighten 87°
°°
°93°
°°
°
6. Remove the M6 x 1.0 bolt.
7. Remove the SST from the camshaft.
8. Remove the SST from the cylinder block lower
blind plug.
9. Rotate the crankshaft clockwise two turns until
the TDC position.
• If not aligned, loosen the crankshaft pulley
lock bolt and repeat from Step 1.
10. Install the cylinder block lower blind plug.
Tightening torque:
1822 N·m {1.92.2 kgf·m, 13.316.2 ft·lbf}
End Of Sie
