ON-BOARD DIAGNOSTIC (DYNAMIC STABILITY CONTROL)
P95
P
End Of Si e
3 INSPECT STEERING ANGLE SENSOR
SIGNAL CIRCUIT FOR OPEN CIRCUIT
• Inspect continuity between DSC HU/CM
terminal (harness side) and steering angle
sensor terminal (harness side) below.
Sensor 1: DSC HU/CM X and steering
angle sensor B
Sensor 2: DSC HU/CM W and steering
sensor C
Neutral: DSC HU/CM U and steering
angle sensor D
• Is there continuity?
Yes Go to next step.
No Repair or replace harness for open circuit between DSC
HU/CM terminal and steering angle sensor terminal, then go
to Step 7.
4 INSPECT STEERING ANGLE SENSOR
SIGNAL CIRCUIT FOR SHORT TO POWER
• Turn ignition key to ON (engine OFF).
• Measure voltage between DSC HU/CM
terminal (harness side) and ground below.
Sensor 1: DSC HU/CM X and ground
Sensor 2: DSC HU/CM W and ground
Neutral: DSC HU/CM U and ground
• Is voltage B+?
Yes Repair or replace harness for short to power circuit between
DSC HU/CM terminal and steering angle sensor terminal,
then go to Step 7.
No Go to next step.
5 INSPECT STEERING ANGLE SENSOR
SIGNAL CIRCUIT FOR SHORT TO GROUND
• Turn ignition key to OFF.
• Inspect continuity between DSC HU/CM
terminal (harness side) and ground below.
Sensor 1: DSC HU/CM X and ground
Sensor 2: DSC HU/CM W and ground
Neutral: DSC HU/CM U and ground
• Is there continuity?
Yes Repair or replace harness for short to ground circuit
between DSC HU/CM terminal and steering angle sensor
terminal, then go to Step 7.
No Go to next step.
6 INSPECT STEERING ANGLE SENSOR
• Inspect steering angle sensor.
(See P44 STEERING ANGLE SENSOR
INSPECTION)
• Is it okay?
Yes Go to next step.
No Replace steering angle sensor, then go to next step.
7 VERIFY TROUBLESHOOTING COMPLETED
• Clear DTC from memory.
(See P46 Clearing DTCs Procedures)
• Is same DTC present?
Yes Replace DSC HU/CM, then go to next step.
No Go to next step.
8 VERIFY AFTER REPAIR PROCEDURE
• Is there any other DTC present?
Yes Go to applicable DTC inspection.
No Troubleshooting completed.
STEP INSPECTION ACTION
