FRONT SUSPENSION
R25
R
No.1 Engine Mount Center Bolt Removal Note
1. Suspend the engine using the SST.
2. Remove the No.1 engine mount center bolt.
Crossmember Bracket Removal Note
Warning
•
••
• Removing the crossmember is dangerous. The crossmember component could fall and cause
serious injury or death. Verify that the jack securely supports the crossmember component before
removing the crossmember bracket.
1. Support the crossmember component with a jack
and remove the nuts.
2. Remove the crossmember bracket.
Front Crossmember Bushing Removal Note
1. Mark the crossmember as shown in the figure
(rear upper side only).
2. Remove the bushings using screw driver (-),
being care not to damage the front crossmember.
A6E7414W016
A6E7414W036
A6E7414W040
A6E7414W032
To Next Page
