POWER DOOR LOCK SYSTEM
S35
S
*1
: Vehicles with double locking system
*2
: Vehicles with theft-deterrent system
2D - - - - -
2E - - - - -
2F
Key
reminder
switch
Key reminder switch
Key reminder switch at on B+ • Inspect key reminder
switch
• Inspect related
harness
Other Below 1.0
2G
Liftgate
open/closed
Door switch
Lliftgate is open (cargo
compartment light switch is on)
Below 1.0
• Inspect cargo
compartment light
switch
• Inspect related
harness
Liftgate are closed (cargo
compartment light switch are off)
B+
2H - - - - -
2I Hazard Flasher unit
Except
vehicles
with theft-
deterrent
system
Transmitter LOCK
button is pressed
B+→Below
1.0→B+
• Inspect flasher unit
• Inspect related
harness
Transmitter
UNLOCK button is
pressed
B+→Below
1.0→B+→Below
1.0→B+
No transmitter
buttons are pressed
B+
Vehicles
with theft-
deterrent
system
Under any condition B+
• Inspect theft-
deterrent control
module
• Inspect related
harness
2J
*1
Security
light output
Instrument cluster
Double locking system operated 1.4 • Inspect instrument
cluster
• Inspect related
harness
Other B+
2K
Door open/
closed
Door switch
Any door is open (any door
switch is on)
Below 1.0
• Inspect door
switches
• Inspect related
harness
All door are closed (door
switches are off)
B+
2L - - - - -
2N - - - - -
2M - - - - -
2O - - - - -
2P
*2
Theft-
deterrent
alarm
control
Theft-deterrent
control module
Ignition switch is at ON position
B+→Below
1.0→B+
• Inspect theft-
deterrent control
module
• Inspect related
harness
Other B+
2Q Lock input Door lock-link switch
Drivers side door is locked:
inspect for continuity to ground
Yes
• Inspect door lock-link
switch
• Inspect related
harness
Drivers side door is unlocked:
inspect for continuity to ground
No
2R Unlock input Door lock-link switch
Drivers side door is locked:
inspect for continuity to ground
No
• Inspect door lock-link
switch
• Inspect related
harness
Drivers side door is unlocked:
inspect for continuity to ground
Yes
2S
Lock/Unlock
input
• Door key cylinder
switch (drivers
side)
*1
• Door key cylinder
switch
(passengers side)
At the moment of key cylinder is
locked
Approx. 2.5
• Inspect key cylinder
switch
• Inspect related
harness
At the moment of key cylinder is
unlocked
Below 1.0
Key cylinder at neutral position Approx. 5
2T - - - - -
2U - - - - -
2V - - - - -
2W
Signal
ground
GND
Under any condition: inspect for
continuity to ground
Yes • Inspect GND
2X - - - - -
Terminal Signal Connected to Test condition
Voltage (V)/
Continuity
Action
