SEAT
S109
S
Lumber support lever disassembly note
1. Remove the pin from the lumber support lever
installation part with rag.
Recliner dial disassembly note
1. Remove the pin from the recliner dial installation
part with rag.
Side cover disassembly note
1. Remove the screws.
2. Disengage the clips.
3. Lift the side cover up in the direction of the arrow,
then unhook it from slide adjuster.
A6E7752W018
A6E7752W019
A6E7752W004
