Mazda 6 2002 - Page 831

SEAT
S113
S
5HB
1. Disassemble in the order indicated in the table.
2. Assemble in the reverse order of disassembly.
.
9 Armrest pad
10 Pole guide
11 Seat back trim
12 Seat back pad
13 Seat back frame
A6E7752W015
1 Headrest
2 Hinge cover
3 Seat cushion trim
4 Seat cushion pad
5 Seat cushion frame
6 Remote button cover
7 Seat back catch cover
8 Child seat anchor cover
9 Seat back board
10 Pole guide
11 Remote button
12 Armrest assembly
13 Cup holder
14 Armrest hinge
15 Armrest trim
16 Armrest pad
17 Seat back trim
18 Seat back pad
19 Seat belt guide
20 Retractor cover
21 Rear seat belt
22 Seat back catch
23 Remote wire
24 Seat back frame
