POWER SYSTEM
T21
T
KEY REMINDER SWITCH REMOVAL/INSTALLATION
A6E811066152W01
1. Disconnect the negative battery cable.
2. Remove the column cover.
3. Disconnect the key reminder switch connector.
4. Remove the key reminder switch.
5. Install in the reverse order of removal.
End Of Sie
KEY REMINDER SWITCH INSPECTION
A6E811066152W02
1. Disconnect the negative battery cable.
2. Remove the column cover. (See S84 COLUMN COVER REMOVAL/INSTALLATION)
3. Disconnect the key reminder switch connector.
4. Inspect for continuity between the key reminder
switch terminals using an ohmmeter.
• If not as specified, replace the key reminder
switch.
End Of Sie
CIGARETTE LIGHTER REMOVAL/INSTALLATION
A6E811067000W01
1. Disconnect the negative battery cable.
2. Remove in the order indicated in the table.
3. Install in the reverse order of removal.
A6E8110W102
A6E8110W117
A6E8110W115
1 Cigarette lighter plug
2 Connector
3Socket
(See T22 Socket Removal Note)
4Ring
(See T22 Ring Removal Note)
