T106
AUDIO AND NAVIGATION SYSTEM
Rear Window Defroster Noise Filter
1. Inspect for resistance and continuity between the
noise filter terminals using an ohmmeter.
• If not as specified, replace the noise filter.
End Of Sie
CONDENSER REMOVAL/INSTALLATION
A6E812466869W03
4SD
1. Disconnect the negative battery cable.
2. Remove the rear package trim.
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.
5HB
1. Disconnect the negative battery cable.
2. Remove the liftgate lower trim.
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.
End Of Sie
A6E8124W036
A6E8124W037
1Bolt
2 Connector
3 Condenser
A6E8124W007
1Bolt
2 Connector
3 Condenser
A6E8124W021
