ENGINE
B1–9
B1
3. Remove the hoist and secure the engine and
transaxle using SST.
No.1 Engine Mount Bracket Installation Note
1. Tighten No.1 engine mount bracket bolt A.
Tightening torque
93.1—116.6 N·m {9.5—11.8 kgf·m, 68.7—85.9
ft·lbf}
2. Tighten No.1 engine mount bracket bolt B.
Tightening torque
93.1—116.6 N·m {9.5—11.8 kgf·m, 68.7—85.9
ft·lbf}
No.1 Engine Mount Rubber Installation Note
1. Tighten through-bolt A on the No.1 engine mount
bracket.
Tightening torque
85.3—116.6 N·m {8.7—11.8 kgf·m, 62.9—85.9
ft·lbf}
2. Tighten through-bolt B on the front crossmember
side.
Tightening torque
93.1—116.6 N·m {9.5—11.8 kgf·m, 68.7—85.9
ft·lbf}
End Of Sie
A6E2215W004
A
B
A6E2324W207
A
B
A6E2324W201
