F2–218
TROUBLESHOOTING
6 Perform self-test function using WDS or
equivalent.
Turn engine switch to ON.
Retrieve any DTC.
Is DTC displayed?
Yes DTC is displayed:
Go to appropriate DTC test.
Communication error message is displayed:
Inspect for following:
• Open circuit between PCM control relay and PCM
terminal 53 or 79
• Open circuit PCM control relay and PCM terminal
69
• PCM control relay stuck open
• Open or poor GND circuit (PCM terminal 65, 85,
103 or 104)
• Poor connection vehicle body GND
No No DTC is displayed:
Go to appropriate DTC test.
7 Access ECT PID.
Inspect ECT PID while warming up engine.
Is PID value correct?
Yes Go to next step.
No Inspect ECT sensor and related wiring harnesses.
8 Access IAT PID.
Inspect IAT PID while running engine.
Is PID value correct?
Yes Go to next step.
No Inspect IAT sensor and related wiring harnesses.
9 Visually inspect CKP sensor and teeth of pulse
wheel.
Are CKP sensor and teeth of pulse wheel okay?
Yes Go to next step.
No Replace malfunctioning parts.
10 Measure gap between CKP sensor and teeth of
pulse wheel.
Specification
1.5—2.5 mm {0.059—0.098 in}
Is gap within specification?
Yes Go to next step.
No Adjust CKP sensor position.
11 Visually inspect CMP sensor and teeth of pulse
wheel.
Are CMP sensor and teeth of pulse wheel okay?
Yes Inspect following PIDs:
(See F2–65 PCM INSPECTION)
• ECT
• IAT
• MAF
• MAP
• RPM
If PID value is not as specified, repair or replace
malfunctioning parts.
If PID value is okay, go to next step.
No Replace malfunctioning parts.
12 Perform EGR system inspection.
Is EGR system okay?
Yes Go to next step.
No Repair or replace malfunctioning part according to
EGR system operation results.
13 Remove parts necessary to inspect
turbocharger.
Note
• Do not remove turbocharger.
Inspect if turbocharger compressor wheel is
bent, damaged, or interfering with housing on
vehicle.
Is there any problem?
Yes Replace turbocharger.
No Go to next step.
STEP INSPECTION RESULTS ACTION
