ENGINE
B2–33
B2
.
A/C Compressor Bracket Installation Note
1. Tighten the A/C compressor bracket bolts in the
order shown.
Tightening torque
38—51 N·m {3.8—5.3 kgf·m, 28—38 ft·lbf}
End Of Sie
N·m { kgf·m, ft·lbf}
38—51
{3.8—5.3, 28—38}
1
2
A6E2324W105
1 A/C compressor bracket
(See B2–33 A/C Compressor Bracket Installation
Note)
2 Seal plate
4
3
1
2
A6E2324W106
