REAR AXLE
M–25
M
Bolt (Trailing Link (Front)) Removal Note
Warning
• Be sure that the trailing link and the knuckle component are supported securely with a jack.
Otherwise, the trailing link and/or the knuckle component may fall, causing death or injury, or
vehicle damage.
1. Verify that the trailing link and the knuckle
component are supported securely with a jack,
and remove the bolts at the trailing link front.
Wheel Hub Removal Note
1. Remove the wheel hub from the knuckle using
the SSTs.
2. If the bearing inner race remains on the wheel
hub, grind a section of the bearing inner race until
approx. 0.5 mm {0.02 in} remains. Then remove
it using a chisel.
Wheel Bearing Removal Note
1. Remove the wheel bearing from the knuckle
using the SSTs.
JACK
A6E63142103
49 G033 105
49 F026 103
49 G033 102
A6J63142104
A6E6312W002
49 F027 005
49 F026 103
49 G030 797
A6J63142105
