M–26
REAR AXLE
Dust Cover Removal Note
Note
• The dust cover does not need to be removed unless it is being replaced.
1. Mark the dust cover and knuckle for proper
installation.
2. Remove the dust cover from the knuckle using a
chisel.
Wheel Hub Bolt Removal Note
Note
• The wheel hub bolts do not need to be removed unless they are being replaced.
1. Remove the wheel hub bolts from the wheel hub
using a press.
Wheel Hub Bolt Installation Note
1. Install the new wheel hub bolts to the wheel hub
using a press.
MARK
A6E63142104
A6E6312W003
A6E6312W004
