REAR AXLE
M–27
M
Dust Cover Installation Note
1. Mark the new dust cover in the same way as the
removed one.
2. Align the marks of the new dust cover and the
knuckle.
3. Install the new dust cover to the knuckle using the
SSTs.
Wheel Bearing Installation Note
1. Install the new wheel bearing to the knuckle using
the SSTs.
Wheel Hub Installation Note
1. Install the wheel hub to the knuckle using the
SSTs.
A6J63142107
STEEL
PLATE
49 H026 104
49 G033 107A
A6E63142105
49 F027 004
49 H026 104
49 G030 797
A6J63142109
49 G033 105
49 H026 104
49 G033 102
A6J63142110
