M–74
ELECTRONIC 4WD CONTROL SYSTEM
Oil Seal Assembly Note
1. Apply the specified oil to a new oil seal lip.
2. Install the oil seal to the coupling case using the
SST.
Companion Flange Assembly Note
1. Install the coupling case to the SSTs as shown.
2. Install the companion flange.
Locknut Assembly Note
1. Secure the companion flange using the SST, and
tighten a new locknut.
Tightening torque
167—226 N·m {17.1—23.0 kgf·m, 124—166
ft·lbf}
End Of Sie
49 W011 102
A6J63222121
49 L027 0A2
A6J63222111
49 S120 710
A6E63222119
