TD–2
TECHNICAL DATA
ENGINE
A6E931001001201
End Of Sie
LUBRICATION SYSTEM
A6E931001001202
TECHNICAL DATA
Item
Specification
Diesel engine
MZR-CD (RF Turbo)
MECHANICAL
Valve clearance
[engine cold]
(mm {in})
IN
0.12—0.18
{0.005—0.007}
(0.15±0.03 {0.006±0.0011})
EX
0.32—0.38
{0.013—0.014}
(0.35±0.03 {0.014±0.0011})
Compression pressure
(kPa {kgf/cm
2
, psi}) [rpm]
Standard
3,500
{35.7, 507.7}
[250]
Minimum
3,100
{31.6, 449.4}
[250]
Maximum difference
between cylinders
196.1 {1.999, 28.44}
Cylinder head bolt length (mm {in})
Standard 159.7—160.3 {6.288—6.311}
Maximum 161.0 {6.338}
Pushing distance of the front oil seal
(from the edge of the oil pump body)
(mm {in})
0—0.5
{0—0.019}
Pushing distance of the rear oil seal
(from the edge of the rear cover)
(mm {in})
0—0.5
{0—0.019}
Pushing distance of the camshaft oil seal
(from the edge of the cylinder head)
(mm {in})
0.5—1.5
{0.020—0.059}
Timing belt auto tensioner rod projection (free length) (mm {in})
12.9—14.6
{0.508—0.574}
Item
Specification
Diesel engine
MZR-CD (RF Turbo)
Oil pressure
(approximate quantity)
[oil temperature: 100°C {212°F}]
(kPa {kgf/cm
2
, psi}) min [rpm]
147 {1.5, 21} [1,000],
343 {3.5, 50} [3,000]
Oil capacity
(approximate quantity)
Total (dry engine)
5.5 {5.8, 4.8}
(L {US qt, Imp qt})
Oil replacement
4.8 {5.1, 4.2}
(L {US qt, Imp qt})
Oil and oil filter replacement
5.0 {5.3, 4.4}
(L {US qt, Imp qt})
