TECHNICAL DATA
TD–3
TD
Recommended engine oil
Note
• The maintenance intervals on scheduled maintenance table (See GI–8 SCHEDULED MAINTENANCE
TABLE) can only be supported with the use of following oils.
End Of Sie
COOLING SYSTEM
A6E931001001203
End Of Sie
FUEL AND EMISSION CONTROL SYSTEM
A6E931001001204
*1
: Excludes temporary idle speed drop just after the electrical loads are turned on.
End Of Sie
Item
Specification
Diesel engine
MZR-CD (RF Turbo)
Engine oil
Grade
API CF CD, CE, CF-4
ACEA B1 or B3
B3
B3 or B4
Viscosity (SAE) 5W-30 10W-40 5W-30, 10W-30
Remarks Mazda genuine Dexelia oil e.g. —
Item
Specification
Diesel engine
MZR-CD (RF Turbo)
Coolant capacity (L {US qt, Imp qt}) 9.0 {9.5, 7.9}
Radiator cap
Cap valve opening pressure
94—122
{0.96—1.24, 13.7—17.6}
(kPa {kgf/cm
2
, psi})
Thermostat
Type Wax, bottom-bypass
Initial-opening temperature (°C {°F})
80—84
{176—183}
Full-opening temperature (°C {°F}) 95 {203}
Full-open lift (mm {in}) More than 8.5 {0.33}
Cooling fan Motor Current (A)
4.4—7.4 (Cooling fan motor No.1)
6.3—9.3 (Cooling fan motor No.2)
Item
Engine
L3 (4WD)
Idle speed
*1
(rpm) 650—750 (700±50)
Item
Engine
MZR-CD (RF Turbo)
Idle speed (rpm) 725—825 (775±50)
Idle-up speed (rpm) When A/C is operated 725—825 (775±50)
Boost relief pressure (kPa {mmHg, inHg}) Approx. –14.5 {–108, –4.27}
