Mercury BRAVO Service Manual

DRIVE SHAFT HOUSING
SERVICE MANUAL NUMBER 28
90-863160 MAY 2000 Page 3A-5
1-Top Cover
2-Screw (4)
3-Flat Washer (4)
4-O-ring
5-Bearing Sleeve
6-Needle Bearing
7-Thrust Race (Shim)
8-Thrust Bearing
9-Clutch Assembly
10 - Thrust Bearing
11 - Thrust Race (shim)
12 - Needle Bearing
13 - Bearing Sleeve
14 - O-ring
15 - O-ring
16 - O-ring
17 - Shifter Shaft Bushing-Upper
18 - Shifter Shaft Bushing-Lower
19 - Shifter Shaft Seal
20 - Vent Plug Seal
21 - Vent Plug
22 - O-ring
23 - U-joint Assembly
24 - Drive Shaft Housing
25 - Stud (4)
26 - Flat Washer (4)
27 - Locknut (4)
28 - Plastic Plug
29 - Shifter Assembly
30 - O-ring
31 - Ball Detent Canister
32 - Back Cover
33 - Flat Washer (3)
34 - Screw (3)
35 - Steel Bearing Adapter (Bravo X, XZ,
XR and Diesel Bravo)
A
- 3M Brand Adhesive
B
- Quicksilver Needle Bearing Assembly Lubricant
C
- Loctite 271
D
- Loctite 277
E
- Quicksilver High Performance Gear Lube (Use On All Bearing Surfaces)
F
-Quicksilver Special Lubricant 101
