POWER STEERING
SERVICE MANUAL NUMBER 28
90-863160 MAY 2000 Page 6A-15
Power Steering System Pressure Test
IMPORTANT INFORMATION
The following instructions are arranged so that a defective part can be detected by the pro-
cess of elimination. It is suggested that the order of the instructions be followed so that the
Power Steering System can be tested effectively.
1. Remove front and rear clevis pins.
2. Retract cable into cable guide tube.
71901
e
a
b
c
d
f
a-Clevis
b-Rear Clevis Pin
c-Forward Clevis Pin
d-Steering Cable End
e-Cable Guide Tube
f-Cotter Pins
