OILDYNE TRIM PUMP SERVICE MANUAL NUMBER 28
Page 5A-2 90-863160 MAY 2000
Trim Pump Specifications
Valve Pressure Specifications
VALVE PSI kPa
Up Circuit 2200-2600 15173-17932
Down Circuit 400-600 2759-4138
Electrical Specification
PUMP AMPERAGE DRAW PSI kPa
115 Amps at: 2200-2600 15173-17932
Torque Specification
DESCRIPTION lb-in. lb-ft Nm
Up Pressure Relief Valve
Down Pressure Relief Valve
Thermal Relief Valve
70 7.9
Pump-to-Adaptor Mounting Screws
End Cap To Motor Housing
Motor-to-Adaptor Mounting Screws
25 2.8
UP Pressure Hydraulic Hose (Black)
DOWN Pressure Hydraulic Hose
(Gray)
110 12
Hex Plug Retainers 44 60
Special Tools
DESCRIPTION PART NUMBER
Trim Pump Test Gauge Kit 91-52915A6
Torque Wrench (lb-in.) 91-66274
Lubricants / Sealants / Adhesives
DESCRIPTION PART NUMBER
Quicksilver Power Trim and Steering Fluid 92-90100A1
Quicksilver 2-4-C Marine Lubricant with
Teflon
92-825407A12
Liquid Neoprene 92-25711-2
