Mercury BRAVO Service Manual

CORROSION PROTECTION - ALL MODELS SERVICE MANUAL NUMBER 28
Page 7A-8 90-863160 MAY 2000
Bravo Two Sterndrive Units
1. Use a 1/2 in. standard socket to loosen screw and remove anodic plate.
2. Scrape anodic plate mounting surface down to bare metal to ensure continuity.
3. Install anodic plate. Torque screw to 30 lb-ft (41 Nm).
50323
a
b
a-Screw
b-Anodic plate
Bravo Three Sterndrive Units
76831
a
a-Anodic Plate
1. Remove plastic cap to gain access to the anode attaching bolt.
76832
a
b
a-Plastic Cap (Removed)
b-Bolt
2. Scrape the mounting surface on gear housing down to bare metal to ensure continuity.
3. Install new anode. Torque to 23 lb-ft (32 Nm).
4. Reinstall plastic cap.
